Decking Cover Tape
Elevo Adjustable Riser Pedestal for Fence Support Spike
Reference:
IHLVO140LG10000
Compatible
Riser pedestal terraces
Joist support riser pedestals
Terraces
Timber decking
Adjustable 43-138 mm riser pedestal for timber or composite decking.
Enables decking construction without any special ground preparation.
Enables decking construction on slopes or to extend existing decking.
Our products in detail
Description
Height adjustment range: from 43 mm to 138 mm (95 mm).
Designed to be located in a metal fence post support.
Use natural timber or aluminium joists, but not composite joists.
This riser pedestal is adjustable for heights of between 43 and 138 mm (i.e. an adjustment range of 95 mm) and is designed to fit into metal post supports for natural timber or composite decks intended for pedestrian use.
Ideal decking construction without the need for any special ground preparation. The base is specifically designed to fit a standard 90 x 90 mm metal fence post support (not supplied). The manual screw adjuster enables precise height adjustment.
Made in France.
10 year warranty
Iso9001
Iso14001
label MORE.
Information sorting
Recycled material.
Keypoints
No excavation or site preparation required.
Compatible with the 60 mm JOUPLAST® height extender (these extenders are stackable to a maximum of 4).
Can be used with Profildeck® aluminium profiles.
Quick and easy to install.
Technical characteristics
Length in mm:
from 43 mm to 138 mm
Length in mm:
90
Color:
Black and Green nut
Material:
Recycled polypropylene
Weight KG:
0,275kg
Packing:
Box of 3 bags of 10 parts
Stackable:
Yes
Installation and Application
The structural elements of decking built on riser pedestals must be natural timber or aluminium joists, but not composite joists.
a question?
Our landscaping experts have the answers
1. What is the Jouplast® Elevo riser pedestal for metal posts used for?
The Jouplast® Elevo riser pedestal for metal posts is designed to create natural timber or composite decking on sloping ground and for extending existing decking. It requires no site preparation and is inserted directly onto a square metal post (not supplied) to provide a stable and height-adjustable solution.
2. How is the Jouplast® Elevo riser pedestal for metal posts used?
The Jouplast® Elevo riser pedestal for metal posts is inserted into a 90x90mm metal post anchored firmly in the ground. Once firmly in place, its height can be adjusted manually using the screw adjuster and/or by adding 60 mm height extenders (up to a maximum of 4). It is designed to support natural timber or aluminium joists and can be used to create decking without any prior excavation or preparation of the ground.
3. Is the Elevo riser pedestal adjustable, and if so, up to what limit?
Yes, Elevo riser pedestal is height-adjustable. It has an adjustment range of 95mm and a maximum height of 138mm. Where greater height is required, up to 4 Jouplast® 60 mm height extenders can be added.
4. On which types of ground can it be installed?
The Jouplast® Elevo riser pedestal for metal posts can be installed on all types of ground, including slopes and loose or uneven ground. It is ideal for sites where traditional preparation (excavation, concrete slab casting etc.) is not feasible, and enables quick and stable construction.
