Edge Finishing Piece for EASIO Decking Riser Pedestal
EASIO Self-Levelling Riser Pedestal for Decking
Compatible
Terraces
Timber decking
Composite decking
Riser pedestal terraces
Joist support riser pedestals
Self-levelling riser pedestals
Self-levelling, height-adjustable riser pedestal for terraces.
Suitable for use with natural timber and composite decking.
Height can be adjusted manually or by using the driver bit.
Our products in detail
Description
Single ergonomically designed screw adjuster. 8 integral lugs for convenient millimetre-accurate manual adjustment.
Reinforced for greater compressive strength.
Self-locking grooves for extra ground support.
The diamond-shaped riser pedestal head enables double joisting and easy joist centring.
The base has a chamfered edge to avoid damaging the underlying surface, and multiple drainage holes to prevent water retention.
Patented self-levelling, adjustable riser pedestal designed for the construction of timber and composite decking for pedestrian use. The many advantages offered by the new EASIO range make it much simpler to build a terrace on rise pedestals.
Firstly, the square flange of this one-piece riser pedestal is designed specifically for easier corner installation.
Its self-levelling diamond-shaped head can be used to: compensate for – or create – gradients of up to 5%, lay double joisting on a single line of riser pedestals, and to use a brace before final fixing.
The two tabs provided on the head also make it easier to centre the joist on the riser pedestal.
The riser pedestal height can be adjusted manually or by using the EASIO/CLEMAN driver bit.
Can be used with the EASIO edge trim clip to lock the riser pedestal self-levelling function.
Made in France.
10 year warranty
Iso9001
Iso14001
compliant with DTU french standards
label MORE.
Information sorting
Recycled material.
Keypoints
The diamond-shaped head enables double joisting on a single row of riser pedestals and the use of a brace before final fixing.
2 fixing tabs enable joists between 40 and 80 mm wide to be laid and centred.
Height can be preset in advance using the driver bit.
Option to use a single or double screw fixing for butt joints.
Double joisting with a 50 mm gap.
2 edge trim supports integrated into the base flange.
One-piece riser pedestal.
Square flange for easy fitting at corners.
Self-levelling head.
Patented system.
UV and frost resistant.
Temperature range of -30°C to +60°C.
Quick and easy to install.
Documentation
Directions for use
PDF - 860 KB
Easio with edge finishing
Directions for use
PDF - 767 KB
Easio without edge finishing
Products compatibility
PDF - 2 MB
Easio
Quantity
PDF - 231 KB
Pavement and wood risers
Technical data sheet
PDF - 562 KB
EASIO Self levelling riser pedestal for decking - adjustable from 40 to 55 mm
Technical data sheet
PDF - 560 KB
EASIO Self levelling riser pedestal for decking - adjustable from 55 to 80 mm
Technical data sheet
PDF - 556 KB
EASIO Self levelling riser pedestal for decking - adjustable from 80 to 130 mm
Technical data sheet
PDF - 541 KB
EASIO Self levelling riser pedestal for decking - adjustable from 130 to 230 mm
Technical characteristics
Color:
Black, green nut
Material:
Recycled polypropylene
Dimensions of the base in mm:
192 mm x 192 mm
Support surface in cm2:
117 cm2
Height in mm:
Available in different sizes
Vertical lug height in mm:
25
Packing:
Changes according to the chosen size of your riser pedestal
Stackable:
Yes
Installation and Application
Facilitates construction of timber and composite decking for pedestrian use. Facilitates construction of decking on uneven or irregular ground.
Compensates for, or can be used to create, gradients of up to 5% on all types of ground.
Uses a specially designed system for the clean edging of timber decking.
Enables the laying and centring of joists between 40 and 80 mm wide. Enables double joisting with a single row of riser pedestals.
Decking for pedestrian use only. For outdoor use only.
a question?
Our landscaping experts have the answers
1. Which types of ground can self-levelling terrace riser pedestals be used on?
It is perfectly possible to install these riser pedestals on well-prepared uneven ground. They work equally well on existing concrete slabs, and can be installed immediately adjacent to existing installations with no problem.
2. Does the ground need to be prepared before installing self-levelling terrace riser pedestals?
The surface on which self-levelling terrace riser pedestals are to be installed should always be prepared in advance. Unprepared ground (e.g. unprepared soil or lawn) may change over time and can be subject to movement, depending on the weight it is required to bear and the weather conditions to which it will be subject (dry periods, heavy rainfall, etc.). For these reasons, it is important to stabilise the ground beneath the terrace to ensure its long-term stability.
3. What is the maximum permissible load for self-levelling riser pedestals?
All self-levelling riser pedestals have the same maximum permissible load of 1 tonne. Imagine that! One tonne is the weight of an adult giraffe.
