Adjustment Key for Cleman Riser Pedestal
CLEMAN Self-Levelling Paving Riser Pedestal
Compatible
Terraces
Paved terrace
Riser pedestal terraces
Paving riser pedestals
Self-levelling riser pedestals
Adjustable self-levelling riser pedestal for tiled, ceramic or paved terraces.
Can be used to create a terrace on uneven or irregular ground.
Can compensate or create gradients of up to 5% on all types of ground.
Our products in detail
Description
4 snappable 3 mm spacers for a smooth surface.
Millimetre-accurate manual height adjustment using the screw adjuster: no other tools are required.
Reinforced for greater compressive strength.
Self-locking grooves on the rear of the riser pedestal remain in contact with the ground for greater stability.
2 edge trim supports integrated into the base flange.
Acoustic damper included. Reduces vibration and resonances by half, compared with a riser pedestal alone.
3 adjustment options: using the driver bit, screw adjuster or special adjustment wrench.
Height-adjustable riser pedestal designed for tiled, ceramic or slab terraces intended for pedestrian use. Self-levelling riser pedestals can be used on uneven or irregular ground to compensate for – or create – gradients of up to 5%, regardless of ground characteristics. The CLEMAN® range allows you to prepare the site by pre-setting the riser pedestals using the driver bit, use the screw adjuster to set the riser pedestal height, and carry out the final millimetres of adjustment using the special adjustment wrench.
FDES
compliant with DTU french standards
label MORE.
10 year warranty
Made in France.
Recycled material.
Iso9001
Iso14001
Information sorting
Keypoints
Can be used to create a terrace on uneven or irregular ground.
CLEMAN® offers 3 options: pre-setting using the driver bit, using the screw adjuster to set the riser pedestal height and using the adjustment wrench to adjust the riser pedestal height.
Quick and easy to fit.
Technical characteristics
Color:
Black, grey nut
Material:
Recycled polypropylene
Basis diameter in mm:
192x192 mm
Support surface diameter in mm:
137
Height in mm:
Different sizes available
Spacer thickness in mm:
4
Installation and Application
This riser pedestal is intended for use only on uneven ground or an existing concrete slab. The terrace can be finished neatly using the paved side finishing plate. See installation instructions.
CLEMAN® riser pedestals are compatible with all paving formats. At least one riser pedestal should be positioned at each corner of the paving slab.
Please refer to the paving/ceramic tile manufacturer’s recommendations to decide whether or not additional riser pedestals may be required. The paving used must be self-supporting and compliant with French classification T7, T11 or F+.
a question?
Our landscaping experts have the answers
1. Which types of ground can self-levelling terrace riser pedestals be used on?
It is perfectly possible to install these riser pedestals on well-prepared uneven ground. They work equally well on existing concrete slabs, and can be installed immediately adjacent to existing installations with no problem.
2. Does the ground need to be prepared before installing self-levelling terrace riser pedestals?
The surface on which self-levelling adjustable terrace riser pedestals are to be installed should always be prepared in advance. Unprepared ground (e.g. unprepared soil or lawn) may change over time and can be subject to movement, depending on the weight it is required to bear and the weather conditions to which it will be subject (dry periods, heavy rainfall, etc.). For these reasons, it is important to stabilise the ground beneath the terrace to ensure its long-term stability. Can also be used with Timber decking tiles.
